ANSI #40 Roller Chain Sprocket CAD Model, 13 Teeth | Keyway & Set Screw Options
Digital Product Only:
You are purchasing downloadable 3D CAD files, not a physical product.
$0.00
Description
Download a high-quality ANSI #40 Roller Chain Sprocket CAD Model designed for mechanical engineering, machine design, power transmission systems, automation equipment, and manufacturing applications.
This model is available in multiple mounting configurations, allowing you to select the option that best matches your project requirements.
| Plain Bore | Standard bore design | No keyway |
| No set screw | Ideal for custom machining | |
| Bore with Keyway & Grub Screw | Finished bore | Precision keyway |
| Grub screw (set screw) included | Ready for shaft mounting | |
| Fully Customizable Version | Custom bore diameter | Custom keyway dimensions |
| Custom grub screw location | Tailored to your project requirements |
Features
✔ ANSI #40 Roller Chain Standard ✔ 13 Tooth Configuration
✔ Accurate Engineering Dimensions ✔ Production-Ready CAD Geometry
✔ Mechanical Design Optimized ✔ Compatible with Major CAD Software
✔ Multiple Configuration Options ✔ Instant Digital Download
Download Information
This ANSI #40 Roller Chain Sprocket CAD Model is available for instant download and can be used for engineering, manufacturing, educational, and product development purposes.
Included Cad File Formats
- STEP(.step / .stp): 3MF (.3mf)
- IGES (.iges / .igs): FBX (.fbx)
- SAT (.sat): DWG (.dwg)
- STL (.stl): DXF (.dxf)
- OBJ(.obj): PDF (.pdf)
Why Buy Our Cad Models
- Instant Download Zero Delay – Start using the models right after purchase.
- Save Time & Focus on Innovation – No need to model from scratch. Trusted by engineers & designers.
- Multiple File Formats – Compatible with SolidWorks/ Fusion 360/ AutoCAD & more.
- Affordable & Scalable – Premium-quality models without the high design cost.
- Perfect for Students & Professionals – Learn build or present with ease
