2 1/2" NPT Female Straight Connector | Download 3D Files (STEP, STL, IGES, DWG)

FREE
Digital Product Only: Digital Download Only — No Physical Product Included.

Available File Formats

STEP(.step / .stp)
IGES(.iges / .igs)
SAT(.sat)
OBJ(.obj)
FBX(.fbx)
STL(.stl)
3MF(.3mf)
DWG(.dwg)
DXF(.dxf)
PDF(.pdf)

This high-precision 2 1/2" NPT Female Straight Connector CAD model is perfect for mechanical engineers, designers, and 3D modelers working with fluid systems, pneumatic circuits, and pipe assemblies. The model follows industry-standard dimensions and is designed for seamless integration into your SolidWorks, AutoCAD, Fusion 360, or 3D printing workflows.

Connection Type Pipe
Connection Style Treaded
Connection NPT Female x NPT Female
Thread Size 2 1/2" NPT
Format Included STEP,STL,IGES,3MF,.PRT,DWG,DXF,PDF,JPEG
Compatibility SolidWorks, Fusion 360, AutoCAD, Free CAD, CATIA, Creo
